DAB Esybox Max

DAB E.Sybox MAX Commercial Variable Speed Pump System

  • Integrated variable frequency drive for peak performance & energy savings
  • Impellers technology allows the motor to operate optimised and effectively
  • Connect up to 4 units for boosted power output for various commercial applications
  • A water-cooled permanent magnet motor ensures silent operation

The E Sybox MAx is another Milestone in the DAB water pumps technology. This variable speed pump marks an evolution of water pressurisation. Designed not only for commercial and building services but also rural and horticultural applications, the DAB Esybox Max exceeds all expectations. Above all, large family homes, local farms and rural lifestyle blocks, hotels, wineries, dairy farms, and rural schools will benefit from this water pressure boosting system.



Therefore, call our water pump experts to discover what the DAB Esybox Max has to offer!

Water Pressure Boosting System with the new DAB Esybox Max

The new and innovative DAB esybox max features the latest advanced pump technology available on the market. The variable speed pressure pump boosts water pressure, especially in commercial applications. The integrated variable frequency drive automatically modulates the motor for best performance without wasting energy. Additionally, the multistage pump has two pressure sensors (suction and pressure) and temperature sensors. With these sensors' help, the system automatically switches on and off according to the user's requirements. Consequently, it maintains a constant water pressure according to the request of multiple water intakes, storeys and buildings.

The Esybox Max is not only a great water pump system. It is first and foremost a new concept in the water booster set industry. This state of the art Dab booster pump is changing the way people think about commercial water pressurisation systems. This slim and compact patented self-priming pump strives for perfection. Delivering constant pressure to large buildings with ease, motels, Airbnb & campgrounds will get the most out of the water pressure boosting system. But also hospitality like restaurants, cafes, wineries, dairy farms or rural schools & kindies will benefit from this exceptional water pressure boosting system.



Up to 20% Energy Savings with the new DAB E.sybox MAX

Installing an E sybox max is an excellent opportunity to invest in significant power savings. This innovative multistage water pump is one of the most energy-efficient commercial pumps. The new impeller technology allows the motor to work optimised and effective way. Therefore, the DAB booster pump runs only at the required speed. Consequently, this stops unnecessary power wasting and also increases the pump lifespan.

State of the art designed permanent magnet motor and DAB inverter technology contribute to enormous energy savings. In addition, this water pressure boosting system has got new hydraulics that enables the pump to be way ahead in terms of energy efficiency. Giving you energy-saving opportunities up to 20% makes the decision to get a Dab E.Sybox MAX easy.



One Of The Most Quiet Commercial Pumps

Setting new standards in the electronic booster set industry; this integrated commercial water pump combinates high performance with outstanding reliability. The water boosting system of the DAB E.Sybox max includes a multistage electric centrifugal pump driven by a water-cooled permanent magnet motor. Cooling the engine with water instead of air ensures low noise in the system and the possibility of installing it in non-ventilated locations. Therefore, the pressure boosting system gives you the comforts of quiet operation without negatively affecting pump performance. Designed for large residential and commercial buildings, you will not notice the operation of this Dab booster pump.



Connect Wirelessly With The Dab E Sybox Max at any time and anywhere

DAB introduces a novelty by creating an interaction of the pump system not only with the plumbing system but also between the pump and the outside world. The innovative interface creates a pathway into the world of services, even outside the product itself. Furthermore, the connection of the Esybox Max with the external input/output devices (e.g. remote alarm, pressure switch, float switch) and with the building management system (BMS) is possible via an extension module. This way, it is very easy to maintain and operate remotely.

Easy monitoring and maintenance: DAB made connecting the management system and the internet straightforward. A high-resolution LCD allows you to complete major tasks manually. However, thanks to DConnect, DAB’s Cloud Service, you can predict problems remotely and act quickly without going onsite. The smart D.Connect app allows you to control the esybox max anytime, anywhere from your phone, PC or tablet. Thus, Iit unlocks many marvellous features, such as alarms, changing parameters, monitoring operations, receiving notifications and preventing the risk of malfunctions or blockage.



Beautifully designed with many helping hands - DAB Esybox Max

The E sybox Max is an excellent exercise in product design. It is created this variable speed pump with meticulous care and, therefore, fittingly won the IF awards 2021. The IF design award is one of the most prestigious design prizes globally. It honours various attributes; product, packaging, interior/ exterior architecture, professional concept, user experience and usability. Finally, the Esybox Max carries many features with its flawless and unique look. Above all, the water pump results from an intense interaction between different people in straight contact with the pump. Engineers, wholesalers, water pump installers, service technicians and end-users have contributed to this outstanding Dab booster pump. The sleek, durable, elegant, and compact design facilitates handling, installation, and maintenance, ultimately contributing to a sustainable environment.



DAB Esybox Max additional features:

  • High definition LCD & control panel; setting parameters and controlling the pump
  • Over under voltage protection; stops electronic to pump in case of over/under voltage
  • Non Return Valve; a one-way valve that protects the pump from reverse flow
  • 2-litre expansion tank reduces pumps starts and protects against thermal fluctuations
  • Esy I/O box allows you to add additional inputs and outputs
  • Double pressure sensors improve the reliability and performance of the pump
  • Dry run protection to prevent pump damage when no water is present
  • Almost fully integrated, the esybox max has few additional parts required

Steve's Pros & Cons

Pros of Dab e.sybox max water pump

If you ask our business customers and us, this variable-speed pressure pump is a DAB Esybox on steroids. The multistage water pump shows its high performance best in commercial applications. However, it is also excellent for super-sized residential homes, lifestyle blocks or rural farms. It is perfect for a wide range of commercial applications, whether it is a rural school, a large dairy farm or a new apartment block with 10 floors. This water pressure system is designed to boost multi-storey buildings and serves them all with ease. Thanks to its modularity, you can connect up to 4 Esyboxes with each other and thus combine four times the performance. This is one of the best performance and efficient commercial water pumps for our water pump experts.

Call us at 0800 Aqua Works to find out how to boost the water in your business.



Cons of DAB ESYBOX MAX commercial pressure booster system

The DAB Esybox Max novelty is so new that we have not yet heard a single negative point from our customers.

Specifications

DAB Esybox Max

  • Brand: DAB
  • Operating pressure: 12 bar or 1200 kPa
  • Constant Pressure Range: 1-12 bar (3 bar by default)
  • Maximum Inlet Pressure: 5 bar
  • Motor Protection: IP X5
  • Max Flow: 290/min or 17.4 m3/h (single unit)
  • Max Head: 113m
  • Warranty: 24 Months
  • Suitable For: Clean Water
  • Type Of Installation: Fixed in vertical position
  • Liquid Temperature: +50°C
  • Dimensions (with docking port) : (L) 375mm x (H) 766mm x (W) 384mm
  • Weight (with docking port): 38kg apx



Dab Esybox Max Models

ESYBOX MAX 60/120T
ESYBOX MAX 66/120M
ESYBOX MAX 85/120T
ESYBOX 2 MAX 60/120M
ESYBOX 2 MAX 60/120T
ESYBOX 3 MAX 60/120M
ESYBOX 3 MAX 60/120MT
ESYBOX 3 MAX 85/120MT
ESYBOX 4 MAX 60/120M
ESYBOX 4 MAX 60/120T
ESYBOX 4 MAX 85/120MT
